FOX T USW 103 and FOX T USW 203

Three Input HDMI & VGA Switchers with Integrated Fiber Optic Transmitters

The Extron FOX T USW 103 and FOX T USW 203 three input switchers with integrated fiber optic transmitters provide long haul transmission of HDCP-compliant HDMI, RGBHV, or HD component video, stereo audio, and RS‑232 signals over fiber optic cabling. They are equipped with many integrator-friendly features for simplified installation. The FOX T USW 103 provides a compact, low profile enclosure that allows for discreet placement. The FOX T USW 203 includes a buffered HDMI output for simultaneous local and remote displays, and a VGA input loop-through, enabling a computer input signal to be monitored without the need for an external distribution amplifier. They are ideal for use in a wide variety of applications with digital and analog sources in a remote location, or in combination with FOX Series matrix switchers for support of enterprise installations of up to 1000x1000 and larger.

Key Features

• Transmits HDMI, RGBHV, or HD component video, stereo audio, and RS‑232 signals very long distances over fiber optic cabling
• All digital technology provides pixel-for-pixel performance with signals up to 1920x1200, including HDTV 1080p/60
• Auto-switching between inputs for simplified operation
• HDCP compliant
• Key Minder^® continuously verifies HDCP compliance for quick, reliable switching
• EDID Minder^® automatically manages EDID communication between connected devices
• Buffered HDMI output enables simultaneous display of the video output signal on local or remote monitors - FOX T USW 203
• Buffered VGA loop-through provides a local monitor output for the VGA input, enabling a computer input signal to be monitored without the need for an external distribution amplifier - FOX T USW 203
• Audio embedding with gain and attenuation control
• RS-232 and contact closure controls
• Compatible with Extron FOX Series HDMI, DVI Plus, DVI, and VGA receivers
• Compatible with Extron FOX Series matrix switchers for distribution systems up to 1000x1000 and larger
• Multimode and singlemode models available
